Location

Port Map for Room x709 and x711

Location (Refer to the map)	Subnet	Port Number	Location (Refer to the map)	Subnet	Port Number
1	None	CCT045945	7	Imager	CCT045942
	CS Firewall	CCT045947		Imager	CCT045944
	Imager	CCT045946		CS Firewall	CCT045943
	New	CCT047945	8	Imager	CCT045939
2	Imager	CCT045948		IAPv2	CCT045941	[cs.ubc.ca #14959] Enabled for ObjetAlaris30, on user-admin subnet, but are not being used as the host and the printer both are disconnected from the network. -- MushfiqurRouf - 07 Dec 2010
	Imager	CCT045950		CS Firewall	CCT045940
	CS Firewall	CCT045949	9	CS Firewall	CCT045934
	New	CCT047946		CS Firewall	CCT045936	[cs.ubc.ca #14691] Enabled for ObjetAlaris30, but were loose -- MushfiqurRouf - 07 Dec 2010
3	Imager	CCT045954		Imager	CCT045935
3	CS Firewall	CCT045955		New	CCT047942
4	Imager	CCT045951	10	Imager	CCT045931
	IAPv2	CCT045953		IAPv2	CCT045933
	CS Firewall	CCT045952		CS Firewall	CCT045932
5	Imager	CCT046123	11	Imager	CCT045929
	Imager	CCT046124		Imager	CCT045928
	Imager	CCT046125		IAPv2	CCT045930
6	Imager	CCT045920	12	Imager	CCT045925
	Imager	CCT045921		IAPv2	CCT045927
	Imager	CCT045922		CS Firewall	CCT045926
	New	CCT047940		New	CCT047941
14	New	CCT047944	13	Imager	CCT045957
				Imager	CCT045959
				CS Firewall	CCT045958

PSM Map
